| General Specifications |
|
| |
|
|
Transducer
|
1 x 2.75"
|
|
Rated output power
|
10W RMS
|
|
Frequency response
|
70Hz - 20KHz (-6dB)
|
|
Signal-to-noise ratio>
|
80dB
|
| |
|
| |
|
| |
|
|
Audio Specifications
|
|
| |
|
|
DAB Tuning range
|
174.928MHz – 239.200MHz (Band-III)
|
|
FM Tuning range
|
87.5MHz – 108MHz (varies by countries)
|
| |
|
| |
|
| |
|
|
Dimensions
|
|
| |
|
|
Dimensions (W x H x D)
|
145 x 167 x 103 (mm) \ 5.7" x 6.6" x 4.1"
|
|
Weight
|
1.15kg (2.54lb)
|
| |
|
| |
|
| |
|
|
Control and Connection Specifications
|
|
| |
|
|
Bluetooth® version
|
4.2
|
|
Bluetooth® profile
|
A2DP V1.2, AVRCP V1.5
|
|
Bluetooth® transmitter frequency range
|
2.402 – 2.480GHz
|
|
Bluetooth® transmitter power
|
0-9dBm (EIRP)
|
|
Bluetooth® transmitter modulation
|
GFSK/ π/4 DQPSK/8DPSK
|
| |
|
| |
|
| |
|
|
Battery
|
|
| |
|
|
Battery type
|
Lithium-ion polymer 11.7 Wh
|
|
Battery charge time
|
4 hours (5V / 0.9A)
|
|
Charging Input
|
5V, 1.2A
|
|
Music playing time
|
up to 15 hours for radio listening (dependent on volume level and audio content)
|
